2025 Chevrolet Low Cab Forward 5500 XD NA



Dealer Fleet Grounded Stock
  • $94,245 SALE PRICE

  • MSRP: $82,710
    • -$1,750
  • Sale Price: $94,245
  • *Please Note: We turn our inventory daily, please check with the dealer to confirm vehicle availability.

Visit our Store

Vehicle Information

VIN: JALEEW162S7P02522
Stock #: S093
Model Code: CT64003
  • Condition New
  • Body Style Regular Cab
  • Exterior Color Ebony Black
  • Interior Color Medium Ash Gray, Cloth Seat Trim
  • Engine ENGINE DIESEL, 4 CYL, 5.2L, 4HK1TC 215HP
  • Transmission Automatic / RWD
  • Fuel Type Diesel Fuel

Highlighted Features

Feature availability subject to final vehicle configuration. Please reference window sticker for more info.
  • Bluetooth®
  • Turbo Charged Engine
  • Cruise Control

Dealer Comments

PIO, MIRROR, OUTSIDE LEFT-HAND AND RI... ENGINE, DIESEL 5.2L 4 CYLINDER, TRANSMISSION, 6-SPEED AUTOMATIC AISIN... AUDIO SYSTEM, AM/FM STEREO WITH AUXIL... Turbo, Running Boards. Ebony Black exterior and Medium Ash Gray interior

KEY FEATURES INCLUDE
Running Boards Traction Control, Bucket Seats, 4-Wheel ABS, 4-Wheel Disc Brakes. Chevrolet 5500 XD LCF Diesel with Ebony Black exterior and Medium Ash Gray interior features a 4 Cylinder Engine with 215 HP at 2500 RPM*.

OPTION PACKAGES
PIO, MIRROR, OUTSIDE LEFT-HAND AND RIGHT-HAND WITH INTEGRAL CONVEX MIRRORS, HEATED, DUAL REMOTE CONTROLS (Port Installed Option), ENGINE, DIESEL 5.2L 4 CYLINDER 215 hp [160.3 kW] @2500 rpm, 452 lb-ft of torque [612.8 Nm] @ 1850-2750 rpm (Governed). 16 valve, four cycle, chain-driven dual overhead camshaft valve train, a cast iron cylinder block, and a cast aluminum cylinder head. Turbocharged, inter-cooled, water cooled EGR, direct injection, electronically controlled common rail fuel system and engine cruise control. Oil level check switch and light. Engine warning system with audible warning for low oil pressure, high coolant temperature, and a protection system that will reduce fueling if excessive coolant temperature is detected (STD), TRANSMISSION, 6-SPEED AUTOMATIC AISIN A465 TRANSMISSION with fifth and sixth gear overdrive with lock up in 2nd, 3rd, 4th, 5th and 6th, PTO capability automatic torque converter lockup in stationary PTO mode. (STD), AUDIO SYSTEM, AM/FM STEREO WITH AUXILIARY JACK, USB PORT AND Bluetooth® (STD).

Horsepower calculations based on trim engine configuration. Please confirm the accuracy of the included equipment by calling us prior to purchase.

All Features

  • Audio system feature, 2 speakers
  • Audio System, AM/FM stereo with auxiliary jack, USB port and Bluetooth® (STD)
  • Audio System, AM/FM stereo with auxiliary jack, USB port and Bluetooth® (STD)
  • LED Headlamps includes integrated LED turn signal indicators
  • Windshield wiper, pulse, wet arm
  • Headlamp washer system
  • Tires, rear, 225/70R19.5 F, all-season (Standard on 4500XD and 5500XD only.)
  • Tires, front, 225/70R19.5 F, all-season (Standard on 4500XD and 5500XD only.)
  • Assist steps
  • Glass, tinted
  • Wheels, 19.5" x 6", steel (STD) (Standard on 4500XD and 5500XD only.)
  • Wheels, 19.5" x 6", steel (STD)
  • PIO, Mirror, outside left-hand and right-hand with integral convex mirrors, heated, dual remote controls (Port Installed Option)
  • Ebony Black
  • PIO, Grille, chrome (Port Installed Option)
  • Rear dome and body lamp switch
  • Lighting, interior dome
  • Windshield washer bottle access on passenger side dash when passenger-side door is open
  • Air conditioning, single-zone manual, integral in-dash mounted
  • Steering wheel, urethane
  • Steering wheel, tilt and telescopic
  • Floor mats
  • Windows, power
  • Cup holders
  • Cruise control, electronic, automatic
  • Seat trim, Cloth
  • Storage, door pockets
  • Storage, seatback pockets
  • Door locks, power
  • PIO, Seat, high back driver only torsion-bar with foam pads suspension system and fixed passenger seat (Port Installed Option)
  • Medium Ash Gray, Cloth Seat Trim
  • PIO, Seat-cover protector, provides protection for all seating positions, for vehicles with driver suspension seat (Port Installed Option)
  • Brakes, 4-wheel antilock, front and rear disc with traction control and stability control
  • Vehicle Application Truck
  • Emissions, Federal certification. Does NOT meet California emissions requirements - TRUCKS CANNOT BE SOLD OR REGISTERED IN CALIFORNIA.
  • Wheelbase, 176" (447.0 cm)
  • Alternator, 140 amps
  • Incomplete vehicle certification
  • Rear axle, 5.57 ratio (Standard on 5500XD only.)
  • Drivetrain, rear-wheel drive
  • GVWR, 19,500 lbs. (8845 kg) (Standard on 5500XD only.)
  • Exhaust, single horizontal outlet
  • Frame, ladder-type channel frame. Full C section straight frame 33.5" (85.1 cm) wide.
  • Front suspension, 8,440 lbs. (3828 kg) tapered leaf springs. Includes shock absorbers and stabilizer bar. (Standard on 4500XD and 5500XD only.)
  • Rear Suspension, 14,550 lbs. (6600 kg), tapered leaf spring with shock absorbers. (Standard on 5500 XD only.)
  • Rear axle, 14,550 lbs. (6600 kg), full-floating with oil lubricated rear wheel-bearings (Standard on 5500XD only.)
  • Air cleaner, heavy-duty, 11" diameter dry paper single element. Air cleaner canister standard with air restriction gauge. Back of cab location.
  • Exhaust brake
  • Fuel tank, 30 Gallon, (113L), stainless steel includes 2 auxiliary fuel ports
  • Battery, dual 750 cold-cranking amps, 12 volt, maintenance free
  • Front axle, 7275 lbs. (3300 kg), reverse Elliot "I"-beam includes integral hydraulic power steering with an 18.8-20.9:1 gear ratio (Standard on 5500XD only.)
  • Rear axle, 5.57 ratio
  • Preferred Equipment Group includes standard equipment
  • California Restriction Acknowledgement. TRUCKS CANNOT BE SOLD OR REGISTERED IN CALIFORNIA.
  • Daytime Running Lamps
  • Airbags, frontal, driver and right front passenger
  • PIO, Fire extinguisher and safety reflector mounting provisions (Port Installed Option)
  • DriveType
    • DriveType: Rear Wheel Drive
  • Fuel Economy
    • City: 0
    • Hwy: 0
    • Combined: 0
  • Fuel System
    • Fuel System: Direct Injection
  • Fuel Tank Capacity
    • Fuel Tank Capacity: 30 gal
  • Fuel Type
    • Fuel Type: Diesel Fuel
  • Horse Power
    • Horse Power: 215
  • Rear Wheel
    • Rear Wheel: Dual
  • Trailering Capacity
    • Trailering Capacity: 0

Warranty

  • Frame Rail: 3 Years/Unlimited Miles 3 Years/Unlimited Miles (No Charge) And Up To 5 Years/Unlimited Miles (50% Charge)
  • Roadside Assistance: 3 Years/Unlimited Miles
  • Rear Axle: 3 Years/Unlimited Miles
  • Corrosion: 4 Years/Unlimited Miles
  • Warranty: <<< Preliminary 2025 Warranty >>>
  • Drivetrain: 3 Years/Unlimited Miles
  • Basic: 3 Years/Unlimited Miles
  • Maintenance: First Visit: 12 Months/12,000 Miles
